Description
Benefits:
Seasonal efficiency conforms to the requirements specified by the ErP regulation for the SEER index.
Acoustic setups SHE and SSN with lower noise levels;
High full load efficiency (EER).
Extended working limitations for starting and operating even under the toughest situations;
A wide range of solutions and kits for easy installation;
Easy access to all internal components.
Options:
Features include a low ambient temperature option (down to -20°C) and high-efficiency EC brushless fans.
Shell and tube evaporator.
A single or double water pump with low or medium head pressure.
Water storage tank;
Full or partial heat recovery;
Heaters with antifreeze protection for heat exchangers, pumps, and water accumulation tanks (if included);
IN/OUT compressor valves.
Hydraulic group protection using covering panels or metallic mesh.
Condenser coils are protected with metallic filters or metallic mesh.
Protective coating for condenser coils, appropriate for installation in harsh situations;
Soft starters cut the starting current by 30%.
Standard features:
The system includes R410A refrigerant, hermetic scroll compressors on a single circuit, crankcase heater compressor and phase monitor, and a plate evaporator.
Axial fans use die-cast aluminum blades and AC motors.
Electrical cabinets have an IP54 protection grade.
Parametric microprocessor control
Electronic expansion valve.
Air-cooled condensers (copper tubes/aluminum fins) with longitudinal “V”-shaped configuration;
Features include high and low refrigerant pressure switches, as well as refrigerant pressure meters for various conditions.
Soft starters cut the starting current by 30%.
Kits:
include antivibration mounts, replica remote user displays (LED or LCD), an RS485 ModBus kit for connecting to supervisor systems, and the xWEB300D EVO supervisor system.
Modularity kit (master/slave arrangement of two to five units).
Soft starters cut the starting current by 30%.
There are three acoustic configurations: basic (HE), low noise (SHE), and very low noise (SSN).
