Description
Benefits:
Very low noise levels;
Ideally suitable for small and medium hydronic cooling systems.
Extend operating limits;
Self-adaptive temperature regulation for efficient operation in systems with low water content.
Designed for installation in restricted places.
Easy-to-use controller with an icon-based dual display.
Easy access to all internal components.
Technical Specifications:
The R410A refrigerant is used in hermetic rotary compressors (mod.020)
scroll compressors (mod.031-171)
double scroll compressors (mod.211-301).
Compressor crankcase heater.
Integrated hydronic module includes pump, storage tank, expansion vessel, safety valve, filling/drain valve, pressure gauge, and automatic bleed valve.
Hydraulic threaded connections are immediately accessible from the unit’s exterior.
Brazed stainless steel plate evaporator.
Axial fans have electronic speed control.
Features include IPX4 protection for electrical panels and phase monitoring.
Factory charged with refrigerant and non-freezing oil.
Extensive factory testing.
Options:
Winter package: minimum ambient temperature of -20°C (-10°C for mod.020), storage tank, medium head pressure pump, condenser air filters, and antivibration mounts.
Configuration of storage tank;
Model 081-301 has a medium/low head pressure pump, a double pump (1 run/1 standby), and an anti-freeze heater for the evaporator, pump, and storage tank (if included).
Accessories & Kits:
Replicated remote user display
serial card (RS485 Modbus)
xWEB300D EVO supervisor system
soft starter
condenser air filters
antivibration mounts.
