Description
Benefits:
Installed motors with integrated inverter technology (compressors, fans, circulators).
High seasonal energy efficiency and reduced noise levels.
A diverse assortment of accessories and kits for customized solutions.
Technical Specifications:
Galvanized carbon sheet steel with polyester powder coating, using R410A refrigerant.
Twin rotary and scroll compressors equipped with integrated inverter technology;
Finned coils made of copper tubing with generously sized aluminum fins;
EC brushless axial fans.
Electronic expansion valve.
Brazed plate heat exchangers in AISI 316 stainless steel with great energy efficiency and low water pressure drops.
Hydraulic circuit (optional) has a single circulator with integrated inverter technology, a storage tank, an expansion vessel, a safety valve, and an air bleed valve.
A contact is supplied inside the electric panel for controlling an external DHW three-way valve (domestic hot water). Only for the variant without an inertial storage tank.
Accessories:
A single circulator with medium head pressure and an integrated storage tank.
Kit:
The features include a remote control, an EMC filter, a three-way valve for domestic hot water, condenser coil filters, a monitoring system, and antivibration mounts.
