Description
Benefits:
The shell and tube heat exchangers made of AISI 304 are corrosion-resistant (biogas side).
Plug-and-play configuration for easy and quick installation.
Higher combustion efficiency in the CHP cogenerator, with reduced biogas usage;
Increased the duration of CHP cogenerator lubricating oil.
Eliminating condensate from biogas distribution lines reduces freezing concerns;
Reduction of corrosive phenomenon produced by the mixture of condensate, CO2, and H2S;
Reduced plant downtime and maintenance expenses.
Improved performance and duration of dry biogas filtering devices.
The “washing” effect removes some of the contaminants present in the biogas.
Technical Specifications:
Biogas side shell and tube heat exchangers in AISI 304
Chiller with Eurovent-certified performance
Integrated economizer heat exchanger, totally of stainless steel: minimizes energy usage and maintains the dew point;
The double demister separator with twin condensate exits ensures an excellent dew point and optimal efficiency.
Heat-insulated standard heat exchangers for maximum system efficiency.
Designed for exterior installations.
Special and tailored versions are available upon request.
Accessories & Kits:
AISI 304 ENERDRAIN automatic condensate drain.
ATEX biogas blower.
Modbus RS485 supervisor system.
