Description
Benefits:
Characteristics that save energy;
Large adsorbent bed: for optimal efficiency, permits a low flow rate and a long contact period;
Superior parts and unique valves with a PVC piston and an aluminum valve body to guarantee maximum dependability and reduce production downtime;
The xDRY midi microprocessor allows for up to 70% energy savings thanks to its five distinct user-programmable operation modes;
The efficiency and effectiveness of the adsorbent bed are enhanced by regeneration air flow in countercurrent;
Phase of gradual re-pressurization: keeps the adsorbent bed from fluidizing and prolongs the adsorbent material’s life;
Pleated 1 micron post-filters as standard; 50/60 Hz power supply and IP54 protection rating;
Easy access to the major parts allows for simple maintenance.
Technical Specifications:
Structure and tanks composed of carbon steel covered with epoxy powder.
Piston valves with aluminum valve bodies and PVC pistons with neoprene joints.
Silencers with a metallic frame are easy to clean.
Control panel designed for outdoor use (IP54);
Power supply: 230 V +/-10% / 1 Phase / 50-60Hz. Different voltages are available on request.
Minimum/maximum operating pressures are 4/16 bar (g) mod. ND003-018 and 4/10 bar (g) mod. ND021-059. Higher pressures are available on request.
Minimum/maximum inlet temperatures are +5/+50 °C.
The minimum and highest ambient temperatures are +5 and +45 degrees Celsius.
Accessories & Kits:
Coalescing oil pre-filters HEF “S” series (0.01 micron) with a condensate discharger.
Post-filters, HEF series “P” (3 micron).
Echo regulation: for accurate regulation of the dew point with minimal power use.
Service kit.
