Description
Benefits:
Seasonal energy efficiency in accordance with ErP EcoDesign requirements for SEER.
Large operational limits for starting up and working even in the toughest conditions.
A variety of alternatives and kits for easy installation;
Easy access to all components.
Advanced electronic control with an integrated web server.
Standard features:
R410A refrigerant, with 4, 6, or 9 scroll compressors on two independent circuits.
Crankcase heater compressor and phase monitor.
Victaulic hydraulic connection kit (comes included with each unit);
Electronic expansion valve.
Axial fans equipped with protective grilles and sickled blades with die-cast aluminum airfoil profiles;
Electrical cabinets have an IP54 protection grade.
Refrigerant charge, non-freezing oil, and factory testing;
Electronic microprocessor controller with a large computing capability and a simple graphical interface;
Modbus RS485 serial output for connection to supervisory systems.
Master/slave arrangement is controllable between two units.
Options:
Available in two versions: low water temperature (outlet water temperature as low as -10°C) and low ambient temperature (down to -20°C).
Stainless steel shell and tube evaporator
A single or twin water pump with low or medium head pressure.
Water storage tank;
IN/OUT compressor valves.
High efficiency EC brushless fans (basis equipment for the SSN variant).
Total heat recovery.
Protection coating for condenser coils, appropriate for installation in harsh locations;
Microchannels condenser coils.
Heat exchangers and hydraulic modules may be equipped with antifreeze heaters.
Metallic mesh filters to protect condenser coils.
Soundproof jacket or casing for compressors (for HE arrangement)
Compressors can benefit from soft starts, which lower inrush current by 20%.
Kits:
The package includes antivibration mountings, a metal mesh filter kit to protect condenser coils, a replica remote user terminal kit, and the xWEB300D EVO supervision system.
Modularity kit for xDRIVE (master/slave from 3 to 8 units).
Metallic mesh filters to protect condenser coils.
Soundproof jacket or casing for compressors (for HE arrangement)
Compressors can benefit from soft starts, which lower inrush current by 20%.
There are three acoustic configurations: basic (HE), low noise (SHE), and very low noise (SSN).
